Product introduction

Parameter type Product specification
Touch size 23"~84"
Interpolation resolution 32767x32767
Touch point number 2~40 point
Positioning error 2mm
Response time 3~15ms
Minimum touch object diameter 3mm
structure size 9.5mm(thickness)x21.3(width)
Input method finger, special pen, Opaque touch induction medium
Output mode coordinate value
Power supply mode USB power supply
Anti light performance All the angle anti ambient lignt
Working voltage typical value +5V DC, allowable range +4.75V~+5.25V
Power waste <1.5W
Interface USB/UART
